15
13b
FIT THE SUPPLIED TOEKICK PANEL
3
4 6 8
5 7
9
1
2
19
19
Important!
Do not overtighten screw.
Where the toekick
meets the bottom
of the tub is the
cut-off point
Mark this point
on the toekick
with a pencil
Lay the toekick face down on
a chopping board or similiar
Smooth the edge with a file.
Be careful of sharp edges.
Snap off the two end tabs
Slide the toekick onto
the mounting rails
either side and screw
the toekick onto the
bottom of tub on
either side.
Mounting rail
Score along with a knife
Turn the toekick over and
score along the same line
Gently snap off the excess
