Floor mount anti-tip bracket.
PRODUCT DATA
MODEL
ELECTRICAL
REQUIREMENTS ***
PRODUCT
WEIGHT
RE24DE 115V/60Hz/15A
130 lbs
(59 kg)
21
1
⁄2"
(54.6 cm)
1"
(2.5 cm)
!
WARNING
Floor mount Anti-tip Bracket must be installed for freestand-
ing applications. Not required for built in applications.
Figure 9
* Depth dimension of rough-in opening may vary depending
on each individual installation. To recess entire drawer "F"
dimension plus 1" (2.5 cm) for thickness of power cord plug
is required.
** Minimum rough-in opening required is to be larger than
the adjusted height of the cabinet.
*** A grounded 15 amp dedicated circuit is required. Follow
all local building codes when installing electrical and appli-
ance.
PRODUCT DIMENSIONS
