Care and cleaning
Replacing the burner parts
Important!
When replacing the burners, make sure that the two locating pins on the bottom of the brass
flame spreader are properly aligned with the locating pin holes on the top of the simmer ring.
Incorrect alignment will produce a potentially dangerous flame and poor burner performance.
Burner cap
Locating pin
Notches
Brass flame spreader
Locating pin hole
Simmer ring
(Do not remove!)
Ignitor
