Parts List Oven Can
ITEM DESCRIPTION 127/227 PART NO. 130/230 PART NO.
1RACK ASSEMBLY 96125 96204
2RACK ROLLER HORIZONTAL 14197-01 14197-01
3 NUT, ROLLER 15021-04
4CONVECTION BAFFLE W/A PORC. 96150-PC 96171-PC
5 CONVECTION ELEMENT 16256 16256-02
* SCREWS (2) 15001-23
6 CONVECTION MOTOR BLADE 16130
7BAFFLE SCREWS (4) 15001-23
8 SCREW 15001-23
9 SET SCREWS (2) 15002-34
10 CONVECTION PAD COVER 96100
* SCREWS (4) 15001-36
11 CONVECTION PAD 96015 96392-02
* SCREWS 15001-23
12 CONVECTION MOTOR COOLING BLADE 16053 16128
* SCREWS (4) 15001-36
13 CONVECTION MOTOR R/H 16327
14 CONVECTION MOTOR BRACKET 96011
15 TEMP SENSOR 16169
* SENSOR SCREWS (2) 15001-40
16 FOOD PROBE (UPPER OVEN ONLY) 16268
17 ROLLER SUPPORT R/H LOWER 96127-02 96127-03
18 ROLLER SUPPORT R/H UPPER 96127-01
19 PROBE COVER (LOWER OVEN ONLY) 96102
20 CATALYST 12063-01
21 PROBE JACK (UPPER OVEN ONLY) 16262
22 RACK ROLLER,VERTICAL / SCREW ASSY. 14197-02
23 OVEN LAMP ASSEMBLY 16242
24 LIGHT BULB 16236
25 LIGHT RECEPTACLE / LENS 16237
26 ROLLER SUPPORT L/H LOWER W/ASSY. 96127-04
27 ROLLER SUPPORT L/H UPPER W/ASSY. 96127-03 96127-02
28 OVEN CAN WELDMENT 96104-01 96104-01
29 BROIL GLASS 16251
30 BROIL ELEMENT 16250
* SCREWS 15001-31
31 BROIL GLASS RETAINER FT / BACK 96090-01
*BROIL GLASS RETAINER LT / RT 96090-02
* SCREWS 15001-31
32 CONVECTION MOTOR ASSEMBLY 96108
*BROIL PAN (ITEM NOT SHOWN) 19021-1
11
* ITEMS NOT SHOWN
