ddrum DD BETA - Page 16

16
(Black)
② SNARE
③ TOM1
⑧ TOM2
⑨ TOM3
(Red)
① HI-HAT
④ CYMBAL1
⑦ CYMBAL2
(Black)
⑤ HI-HAT CTRL
⑥ BASS DRUM CTRL
①
③
④
⑤ ⑥
⑦
⑧
⑨②
Sound Cable
L2
(Black)
x6
L3
(Blue)
x3
Connect the Sound
Cables to the Drum
Pads,Pedals and Sound
Module.
Black: mono
Red: stereo
L2
L2
L3
