ddrum DD BETA - Support Stand; Spare Parts

7
Spare Parts Connectors
P4~P7 C1 C2 C3 C4
Ø2.22 Pad
Connector
Ø1.27 Pad
Connector Adjustable Bar
U-shape Plate &
Double Screws
x2 x2 x2 x2 x1
Parts
P1 P2 P3 P4 P5 P6 P7
Floor Pad
Ø3.81 (cm)
Stopper
Ø2.22 (cm)
Stopper Bolt Washer Bolt Nut
x4 x2 x8 x14 x14 x8 x22
Support Stand
S1
Ø3.81 x40 (cm) x1 x2
S2
Ø3.81 x57 (cm) x1
S3
Ø3.81 x40 (cm) x1 x2
S4
Ø3.81 x75 (cm) x1 x3
S5
Ø2.22 x65 (cm) x1 x4
S6
Ø3.81 x75 (cm) x1 x2
S7
Ø2.22 x40 (cm) x1 x1
S8
Ø2.22 x40 (cm) x2
S9
Ø1.27 x40 (cm) x2
S10
Ø1.27 x20 (cm) x3
