100.6702.6 - 8 -

Figure 3 - Multiple Meter Assembly

Seat the seal o-ring in the outer counterbore of the of the gas outlet connector on the ﬂow

meter. Then mount the adjacent ﬂow meter assembly. Do not seat the o-ring on the protu-

sion of the adjacent ﬂow meter assembly.

Assemble the meter-rate valve assemblies and install the adaptor ﬁtting as indicated.

Then mount as described in Figure 4 and complete the interconnections as shown in

Figure 1.
