9.3 Parts List: 1824G & 2424G (cont.)
ITEM COMPONENT MODEL 1824G
PART #
MODEL 2424G
PART #
1 Top Assembly, Short Stack 823-3622 24248
* Top Assembly, Std. (Old-Style High Stack) 823-3699 823-3264
* Top Assembly, Short Stack (Old Style) 823-3577 106-1619SP
2 Hose Support, LJS Systems 210-2006 210-2006
3 Basket Hanger (Old Style) 24-0130 24-0267
4 Fry Basket, 6 x 8-¾ x 16-¾" 803-0301 803-0301
5 Vessel, Flatbottom (Front Drain, No
Filtration)
24024-1SK 24023-1SK
* Vessel, Flatbottom (Front Drain, Front
Return)
823-3507SP 823-3466SP
* Vessel, Flatbottom (Rear Drain, Front
Return)
24024-3SK 24023-3SK
6 Structural Back, Short Stack 24-0331-1 200-1607
* Structural Back, Standard 200-1608 24-0380
7 Plenum Assembly, Short Stack 24039 24040
* Plenum Assembly, Standard 24041 24042
8 Sail Switch (Air Prover) 11162 11162
9 Outlet Duct Assembly 823-3166 823-3166
10 Blower Motor 807-3573 807-3573
11 Inlet Duct Assembly 823-3162 823-3162
12 Airgate- Inlet Duct Assembly 200-1428 200-1428
13 Duct, Door Access 210-1365 210-1365
14 Spreader, Side Flame 210-1409 210-1409
15 Baffle, Secondary Air 823-3190 823-3190
16 Insulation, Inswool 816-0535 816-0535
17 Back, Fire Box 200-2731 200-1391
18 Guard, Fire 823-3170 823-3170
19 Guard, Temperature/High-Limit Probe 200-1411 200-1411
20 Divider, Vessel 24103 24103
21 Tray, Crumb 24003 823-3189
22 Panel, Side- LH 823-3168 823-3168
* Panel, Side- RH 823-3169 823-3169
23 Top Cap (Canopy) 210-2028 210-1438
24 Marine Edge, Dual N/A 24269
* Marine Edge, Single 823-3497 823-3195
* Marine Edge, 1824 To 1824 24255 N/A
* Marine Edge, 2424 To 2424 N/A 823-3718
* Marine Edge, 1824 To 2424 24257 24257
25 Panel, Control (Red Light/Green Light) 210-2471 210-2614
* Panel, Control 210-1655 24-0080-3
26 Valve, Drain,1-¼” (1" Standard Port) 810-2052 810-2052
* Valve, Drain,1-¼” With Microswitch Holder 823-3463 823-3463
27 Elbow, 1-¼” NPT 813-0070 813-0070
28 Microswitch, Drain Valve 810-2103 810-2103
* Holder, Microswitch 200-1603 200-1603
* Screw, 4-40 x 1" Slotted Head 809-0846 809-0846
29 Cover, Thermostat Entry 200-1671 200-1671
30 Switch, Power- Green (Carling) 807-3574 807-3574
* Switch, Rocker- Red (Old Applications) 1680 1680
* Not Illustrated
