9.3 Parts List: 1824G & 2424G (cont.)
ITEM COMPONENT MODEL 1824G
PART #
MODEL 2424G
PART #
31 Switch, Oil-Tight Assembly 44382 44382
* Switch, Reset (Carling) 807-3576 807-3576
* Plug, Switch Hole 807-3575 807-3575
* Cover, Thermatron Entry 24-0015 24-0015
32 Pilot, Burner Assembly- Natural 106-0849SP 106-0849SP
* Pilot, Burner Assembly- Propane (LP) 24153 24153
33 Magnet, Door Catch 810-0066 810-0066
34 Thermocouple 807-3550 807-3550
35 Bracket, Pilot Support 200-1416 200-1416
36 Transformer, Electronic Ignition 807-3551 807-3551
37 Ignition Module 807-3554 807-3554
* Ignition Cable 106-1644SP 106-1644SP
* Ignition Cable, Fenwall 1908 1908
38 Ignitor/Sensor Assembly (Retrofit) 106-1983SP 106-1983SP
* Sensor Wire 106-1645SP 106-1645SP
39 Gas Valve- 24V- Natural 807-3555 807-3555
* Gas Valve- 24V- Propane (LP) 807-3690 807-3690
* Gas Valve- 120V- Natural 810-2156 810-2156
* Gas Valve- 120V- Propane (LP) 810-2323 810-2323
40 Sensor Probe Assembly (G0 Board) 106-0882SP 106-0882SP
* RTD Sensor Probe (Old-Style Thermatron) 106-1977SP 106-1977SP
41 Face Plate (Thermatron- SCF/UFF) 820-0135 820-0135
* Face Plate (Thermatron- Single Unit) 820-0136 820-0136
* Thermatron Retro Kit 24233-1 24233-1
* Potentiometer Assembly, G0 807-3536 807-3536
* Interface Board (G0 Thermatron) 115VAC 807-3536 807-3536
* Knob, G0 (Thermatron) Control 816-0534 816-0534
42 Thermostat, Operating 807-3515 807-3515
43 Knob, Operating Thermostat 816-0546 816-0546
44 Thermostat, High-Limit- 435°F Man. Reset 807-3559 807-3559
* Thermostat, High-Limit- 435°F Auto Reset 807-3516 807-3516
45 Support, Manifold- Left- and Right-Hand 200-1670 200-1670
46 Manifold Assembly, Gas 810-2168 810-2168
* Plug, 1/8" NPT- Square Head 813-0705 813-0705
47 Burners, Tube 810-2129 810-2129
48 Orifice, Natural Gas 810-2051 810-2051
* Orifice, Propane (LP) Gas 810-2317 810-2317
49 Leg 1731-2 1731-2
50 Caster, With Brake (Single Stud) 1942 1942
* Caster, Without Brake (Single Stud) 1943 1943
* Caster, Swivel-5" with Brake (4-Hole) 810-0357 810-0357
* Caster, Swivel-5" w/o Brake (4-Hole) 810-0356 810-0356
* Caster, 5" rigid (4-hole) 810-0378 810-0378
51 Door Assembly, 12/90-12/93 24270 24271
* Door Assembly, After 1993 210-2002 210-2001
* Door Pin (Required With 12/90 - Current) 210-2119 210-2119
* Door Assembly, SCF N/A 24274
* Door Assembly, Lexington Models 106-1751SP 106-1649SP
* Door Assembly- Prior to 12/90 (Welded
Door Pins)
24019 24020
51a Hinge Bracket, Lower 200-1675 200-1675
52 Handle, Door (With Screws) 810-2105 810-2105
* Not Illustrated
