DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-40
2.10 Basket Lift Components; D50, D60, and D80 Series Fryers (cont.)
ITEM PART # COMPONENT
106-1914 Basket Lift Assembly (D50)
106-1870 Basket Lift Assembly (D60)
106-1926 Basket Lift Assembly (D80)
1 200-1376 Bracket, Restraining
2 200-2069 Member, Lift Control Arm
Channel, Support Autolift
3 200-3094 Channel (D80)
* 200-2735 Channel (D60)
* 200-3072 Channel (D50)
4 809-0879 Receiver,
3
⁄
4
" Tinnerman Stud
5 809-0907 Screw,
3
⁄
8
" x
1
⁄
4
" Shoulder
* 809-0863 Nut,
5
⁄
16
-18 Hex
6 810-2140 Bushing (Bronze), Oiltite
3
⁄
8
" x
1
⁄
4
"
7 813-0035 Bushing (Bronze), Oiltite .640 I.D.
Back, Basket Lift Motor
8 824-0996 Back (D80)
* 824-0958 Back (D60)
* 824-0990 Back (D50)
Cover, Basket Lift Motor
9 824-0997 Cover (D80)
* 824-0959 Cover (D60)
* 824-0991 Cover (D50)
10 200-1693 Plate, Motor Mounting
11 807-0107 Motor, Gear
12 823-3626 Switch, Limit Cam
13 807-2104 Microswitch
* 810-2144 Spacer
* 809-0846 Screw, 4-40 x 1"
* 809-0842 Nut, 4-40 Nylock
Motor Housing
14 200-3150 Housing, Front (D80)
* 200-2736 Housing, Front (D60)
* 200-3087 Housing, Front (D50)
15 200-3114 Housing, Bottom (D80)
* 200-2739 Housing, Bottom (D60)
* 200-3079 Housing, Bottom (D50)
16 200-3116 Housing, Back (D80)
* 200-2740 Housing, Back (D60)
* 200-3091 Housing, Back (D50)
17 807-0140 Connector,
3
⁄
8
"
* 807-3087 Basket Lift Timer, 120V, 60 Hz, 15 min.
* 810-1822 Timer Knob
* 810-1823 Timer Button
* 826-1552 Basket Lift Timer Kit
18 823-3505 Left Basket Lift Arm
19 823-3499 Right Basket Lift Arm
* Not illustrated.
