DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-19
2.5.1 1.5” Oil Drain Manifold, Drain Flush, and Drain Valve Components (cont.)
ITEM PART # COMPONENT
1 823-3221 Elbow with Bracket, Left
* 823-3222 Elbow with Bracket, Right
2 823-5167 Drain Pipe, Left Side
3 210-2311 Clamp, Center Drain Pipe
4 823-4931 Drain Pipe, Right Side
5 813-0749
Tee, 1
1
⁄
2
" NPT With Handle Bracket
6 200-5621 Drain Manifold Tube, 17”
* 200-1827 Drain Manifold Tube, 13”
7 813-0659
Pipe Cap, 1
1
⁄
2
"
* 813-0391 Nipple, 1 ¼” x Close
* 813-0748 Tee, 1 ½” NPT x 1 ¼” NPT (with handle bracket)
8 809-0884
Nut, Slip-joint 1
1
⁄
2
"
* 816-0544 O-ring, Slip-joint Nut
9 813-0686
Bell Reducer, 1
1
⁄
2
" x
1
⁄
2
" NPT
10 810-1057
Flex Line,
5
⁄
8
" x 13"
11 813-0051
Coupling,
1
⁄
2
" NPT
12 813-0165
Elbow, Street
1
⁄
2
" x
1
⁄
2
" 90°
13 810-1668
Adapter,
5
⁄
8
" O.D. x
1
⁄
2
" Male (use with 810-1057 and 810-1069)
* 810-1669
Adapter,
5
⁄
8
" O.D. x
1
⁄
2
" Female (use with 810-1057 and 810-1069)
14 810-1069
Flex Line,
5
⁄
8
" x 29
1
⁄
2
"
* 806-6849 Tilt Switch, Drain Valve
DRAIN VALVE COMPONENTS
15 106-1401 Bracket, Microswitch (optional on some units)
16 200-1617 Washer, Drain Valve (use without microswitch)
17 210-2029 Bracket, Microswitch Activator
18 210-4727 Handle (Actuator), Drain Valve, Round
* 823-3405 Handle (Actuator), Drain Valve, Flat
* 823-3440 Handle, Push/Pull Drain
* 809-0885
Washer,
3
⁄
8
" x 1 x .083"
* 809-0843 Cotter Pin
* 816-0547 Cap, Red Vinyl for Handle
19 807-2104 Microswitch (optional on some units)
20 809-0842 Nut, Nylock #4-40 (microswitch to bracket)
21 816-0220 Insulation, Microswitch
22 200-1257 Retainer, Nut
23 810-2127
Drain Valve, 1
1
⁄
2
" Full Port (with washers & nut)
24 810-2052
Drain Valve, 1
1
⁄
4
" (1" standard port)
* 810-1338 Drain Valve, 1" (D20 only)
* 200-2371 Handle, Valve Lever (for use with 810-1338 and 823-3440 only)
25 810-2126
Drain Valve, 1
1
⁄
4
", Full Port
* 810-1018
Drain Valve, 1
1
⁄
4
", Left
* 210-2342 Drain Extension, Left
* 210-2343 Drain Extension, Right
* Not illustrated.
