DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-27
2.7.1 Oil Return and Oil Flush Components; D & FPD65 Models (cont.)
ITEM PART # COMPONENT
1
Microswitch Bracket Assembly, Oil Return
106-1824 Bracket, Oil Return Microswitch, Left
106-3595 Bracket, Oil Return Microswitch, Right
201-4455 Bracket, Oil Return Microswitch, Left (FPD)
202-4455 Bracket, Oil Return Microswitch, Right (FPD)
810-2144 Spacer, 4-40
1
⁄
4
" x
3
⁄
8
" Aluminum
807-2104 Microswitch, Oil Return
809-0846 Screw, 4-40 x 1" Slotted Head
809-0842 Nut, 4-40 Nylock
200-1341 Bracket, Microswitch Rod
809-0360 Screw, #8 x
3
⁄
8
" Hex Washer Slotted Head
826-1389 Screw,
1
⁄
4
-20 x
3
⁄
4
" Hex Head
809-0428 Screw,
1
⁄
4
-20 x ½” Hex Head
809-0823 Nut,
1
⁄
4
-20 Nylock
809-0070 Nut,
1
⁄
4
-20 Hex SS
2 810-0697 Disconnect, Male Suction Tube
* 826-1392 O-rings, for Male Disconnect (pack of 5)
3 813-0608 Coupling, Full,
1
⁄
2
" NPT BM
4 823-3188 Suction Manifold Assembly
5 813-0062 Elbow, 90° BM
6 813-0515 Nipple,
1
⁄
2
” NPT x 12" BM
7 813-0173 Union,
1
⁄
2
" NPT BM
8 813-0251 Nipple,
1
⁄
2
” NPT x 4
1
⁄
2
" BM
9 813-0672 Nipple,
1
⁄
2
” NPT x 8" BM
10
Oil Suction Start Fitting
* 813-0022 Nipple,
1
⁄
2
" NPT x Close
* 813-0156 Plug,
1
⁄
2
" NPT Hex Head
* 813-0003 Tee,
1
⁄
2
" NPT BM
11 809-0885 Washer,
3
⁄
8
" x 1" x .083"
* 809-0843 Cotter Pin, Plated
12 823-3344 Handle (Actuator), Oil Return Valve
13 823-3187 Handle, Oil Return Left Fryer (UFF System)
14 823-3198 Handle, Oil Return Right Fryer (UFF System, Fryer 3 & 4)
* 823-3481 Handle, Oil Flush Valve
* 816-0547 Cap, Drain Valve Handle, Red
15 816-0548 Cap, Oil Return Handle, Yellow
* 816-0549 Cap, Oil Flush Handle, Blue
16 810-2100 Motor, Pump 120-230V
17 810-2098 Pump, 8 GPM
* 810-2252 Pump, Chili’s, 5 GPM
* Not illustrated.
