DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-30
2.8 UFF Filtration Components
2.8.1 UFF Filtration Components; D50 Series Fryers
1
2
3
4
5
6
7
8
9
10
11
12
ITEM PART # COMPONENT
1 106-2115SP Filter Pan
2 809-0805 Screw, ¼-20 x ½"
3 809-0428 Screw, ¼-20 x ½" Steel
4 809-0820 Nut, Oval Locking, ¼-20
5 823-4794 Insert, Caster
6 810-2805 Caster, 2”
7 823-3574 Support Grid, Bottom Pan Screen
8 803-0289 Filter Paper, 22” x 34" (100 sheets per box)
9 823-3573 Hold-down Ring, Weighted
10 823-4320 Crumb Basket
11 106-0752SP Lid Assembly, Front
12 106-1755SP Lid Assembly, Rear
* 106-3230SP Lid Assembly, One Piece, Chili’s
* 106-2568SP Wand Assembly
* Not illustrated.
