DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-32
2.8.3 UFF Filtration Components; D60 and D80 Series Fryers
1
2
3
4
5
6
7
8
12
10
11
9
ITEM PART # COMPONENT
1 106-0749SP Filter Pan (UFF 60)
* 106-1584SP Filter Pan (UFF 80)
* 106-4521 Filter Pan (UFF 100)
2 823-3365 Support Grid, Bottom Pan Screen
3 803-0289 Filter Paper, 22 x 34"
100 sheets per box
UFF 60
* 803-0303 Filter Paper, 26 x 34" (100 sheets per box) (UFF 80)
4 823-3361 Hold-down Ring, Weighted (UFF 60)
* 823-3439 Hold-down Ring, Weighted (UFF 80)
5 823-4320 Crumb Basket (UFF 60)
* 823-3443 Crumb Basket (UFF 80)
6 106-0752SP Lid, Front (UFF 60)
* 106-1587SP Lid, Front (UFF 80)
7 106-0753SP Lid, Rear (UFF 60)
* 106-1588SP Lid, Rear (UFF 80)
8 809-0428 Screw, ¼-20 x ½" Steel
9 823-4794 Insert, Caster
10 809-0820 Nut, Oval Locking, ¼-20
11 809-0805 Screw, ¼-20 x ½"
12 210-2805 Caster, 2"
* Not illustrated.
