DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-37
2.9.3 SUFF Filtration Components; D60 and D80 Series Fryers
1
2
3
4
5
6
7
8
12
9
10
11
ITEM PART # COMPONENT
1 823-3774 Filter Pan (SUFF 60)
* 823-3821 Filter Pan, (SUFF 80)
* 813-0684 Plug, Hex Socket, 3/8" NPT
* 813-0679 Plug, 1/8" SS Square Head (Female Disconnect)
2 823-3768 Support Grid, Bottom Pan Screen (SUFF 60/80)
3 803-0289 Filter Paper, 22” x 34" (SUFF 60/80)
4 823-3770 Hold-down Ring, Weighted (SUFF 60)
* 823-3849 Hold-down Ring, Weighted (SUFF 80)
5 823-3736 Crumb Basket (SUFF 60/80)
6 823-3766 Filter Pan Cover, Front (SUFF 60)
* 823-3739 Filter Pan Cover, Front (SUFF 80)
7 823-3767 Filter Pan Cover, Back (SUFF 60)
* 823-3741 Filter Pan Cover, Back (SUFF 80)
8 809-0428 Screw, ¼-20 x ½" Steel
9 823-4794 Insert, Caster
10 809-0820 Nut, Oval Locking, ¼-20
11 809-0805 Screw, ¼-20 x ½"
12 810-2805 Caster, 2"
* Not Illustrated
