RUNNER 19
N) PARKING BRAKE
The electromechanical immobilization mechanism acts automatically and consequently keeps the
vehicle in the braked position switching off the key .
O) PLUG-SOCKET FOR CONNECTING THE BATTERY TO THE VEHICLE
The battery socket is used for connecting the battery to the vehicle’s electrical system.
The socket and plug are inserted by pressing in the obligatory direction.
The battery plug must be disconnected from the system and connected to the battery charger for
recharging operations.
ATTENTION !
All the elements are positioned on the scrubber-drier for easy operation by the operator, so that
removing the plug will cause sure disconnection of the vehicle from the power supply. This device
must be used in case of a short circuit or poor functioning of the operating commands and for
maintenance operations.
P) TOWER LIGHT
Q) SOLUTION REGULATOR COCK
It is positioned under the vehicle base and makes it possible to regulate the flow rate of the solution to
be used on the floor. The flow rate can be adjusted between 0 to 4 l/min or from 4 to 8 l/min depending
on the position of switch F). Turning the lever clockwise will increase the solution flow.
R) SEAT
Adjust the position of the seat longitudinally before using the scrubber-drier to make working safe and
more comfortable.
