Dectron DS Series – Outdoor OMM 14 September 2020
Layout and Components
The general layout and components location is the same for all dehumidifiers of current type, however some may
vary, based on the dehumidifier’s specific options – refer to submittal documentation. Pic. D.1-L and D.1-B below
shows all/most available options, some of which may not be present on your dehumidifier.
Dehumidifier Main Components - SLX
• Main Blower (1) is in the main blower compartment next to the Main Electric Panel (2) and Compressor
Compartment (3).
• Min Outdoor Air (OA) Opening (4) is equipped with a louver and, as an option, with a motorized damper and
filter(s). The Manual OA Damper (5) is usually used to set proper amount of outdoor air intake.
2
1
3
4
5
6
7
8
9
11
10
12
13
14
15
19
18
17
Pic. D.1-L
61
66
62
63
64
65
