UTILISATION

Thisproductisintendedtoextractfumes,fats,andsteamfromcooking.Ithasbeendesigned

andmadeforuseeitherinthesuctionorlterversions.

VERSION EVACUATION exterieure

Thehoodisequippedwithanairoutlet(Fig.AFIGURE5)toconveysmokeoutwards(theue

pipeandxingangearenotsupplied).

Check valve blockage

Warning:Beforeconnectingtheairexhausthose,makesurethatthecheckvalvesarefreeto

turnoverfreely.

In ltering application that the stop valve doesn’t permit the entrance of wind and exhau-

sted air.

Filtering version

Inthecaseanexhaustingholeisnotpossible,thehoodcanbeusedinlteringversion.Forthis

modecharcolltersaretobettedinsidethehood.Filteredairwillbeevacuatedinthekitchen

troughaductthatconveystheaironasideofthecabinet(picture6bis).

ELECTRIALHOOKUP

This appliance conforms to the European Directives 2006/95/EC (Low Voltage Directive)

and 2004/108/EC (Electromagnetic Compatibility).

Whenyouinstalltheapplianceandcarryoutmaintenance,itmustbeunpluggedfromthepower

sourceorthefusesmustbedisengagedorremoved.Electricalhookupmustbecarriedout

beforetheapplianceisinstalledinthecabinet.

Checkthat:

-thepowersourceissucient,

-powercordsareingoodcondition,

-Thediameterofthecablesconformstoinstallationregulations.

- MOUNTING THE HOOD

Installation must conform to the regulations in force regarding the ventilation of

enclosed environments. In France, these regulations are container in the DTU 61.1 of the

CSTB. In particular, discharged air must not be channelled into a conduit used for exhaust

discharge or discharge from devices that operate with gas or other combustible materials.

The use of unused conduits is not permissible without the approval of a qualied techni-

cian.
