-REMOVAL OF THE FILTER CARTRIDGE

-MOUNTING THE CARBON FILTER

Theremovalandttingofthegreaseandcarbonltersneedtobecarriedoutwiththedown-

draftintheopenposition.Toopenthedowndraft,pushtheON/1key.Nextremovethefront

panel,pushingonbothsidesofthetoppartatthesametime(Fig.1d).Thepanelwillrotate

forwardstomakeitpossibletoaccessthegreaselters(Fig.8b).Removethegreaseltersto

accessthecarbonlters(Fig.9c).Thecarbonltersshouldbechangedaccordingtothefre-

quencyofdowndraftuseandinanycase,onceevery6months.

Warning:thestainlesssteelpanelthatprotectstheltersneedstoberepositionedcorrectly.

Incorrectpositioningcancausethehoodtostopcompletely.

- ELECTRIAL HOOK UP OF THE HOOD

WARNING: The electronic board for the controls needs to be installed beneath the work

top, close to the body of the hood and at a minimum distance of 65 cm from all substances

or ducting for ammable substances (gas pipes or ducting for specic liquids)

USEFUL ADVICE: We recommend tting the electronic board at a height of at least 10 cm

from the ground and at a suitable distance from all heat sources

(e.g., the side of an oven or cook top).

This appliance is tted with an H05 VVF 3 conductor, 0.75 mm2 (neutral, phase, and

ground) power cable. This can be hooked up to a 220 – 240 V mono-phase electrical

network by way of a CEI 60083 regulation power socket that must remain accessible after

installation, in conformity to installation regulations.

We decline all responsibility in case of accident caused by a lack of ground connection

or incorrect ground connection. The fuse used must be 10 or 16 A. If the power cable is

damaged, call the after-sales service to avoid any risk.

Attention

Ifthehoodpresentssomeformofanomaly,unplugtheapplianceorremovethefusecorre-

spondingtotheappliance’spowerline.
