DeDietrich Diematic iSystem User Manual

L000161-D
TS + B AB
0-10V
S AMB C
4 3 2 1 2 1 + -
S AMB B
2 1
S AMB A
2 1
S SYST + TA -
S ECS S EXT S DEP C
2 12 12 12 1 2 1
S DEP B
2 1
SCU
On/off
OT
BL
RL
PCU
PUMP
6
3
2
4
9
8
5
7
1
M
A
Do not connect anything to the terminal block.
Z
Connect the load pump from the buffer tank.
E
Connect the sensor from the storage tank (Package
AD250).
R
Buffer tank.
T
Connect the DHW tank anode.
If the tank is not fitted with an impressed current
anode, put the simulation connector in place
(delivered with the DHW sensor - package
AD212).
Y
Connect the DHW sensor (Package AD212).
U
Connect the heating pump (Circuit A).
I
Solar sensor probe.
O
Connect the solar station to the solar collectors.
Settings to be made for this type of installation
Parameters Access Settings to be made See
INSTALLATION
Installer level
#SYSTEM Menu
EXTENDED
¼ "Displaying the parameters in extended mode", page 33
I.SYST
(1)
Installer level
#SYSTEM Menu
BUFFER TANK
¼ "Setting the parameters specific to the installation", page
33
(1) The parameter is only displayed if INSTALLATION is set to EXTENDED
Diematic iSystem For C 330 / C 630 ECO 4. Installation
31082018 - 7600691-001-06
18
