DeDietrich Diematic iSystem User Manual

User level - #SETTING Menu
Parameter Adjustment range Description Factory setting Customer
setting
SUM/WIN 15 to 30 °C Used to set the outside temperature
above which heating will be shut down.
4 The heating pumps are shut down.
4 The burner will only start for
domestic hot water needs.
4 The symbol p appears.
22 °C
NO
Heating is never shut down
automatically
CALIBR.OUT Outside sensor calibration: Used to
correct the outside temperature
Outside
temperature
CALIBR.ROOM A
(1)(2)
Calibration of the room sensor on
circuit A
Make this setting 2 hours after switching
on, when the room temperature has
stabilised
Room temperature
of circuit A
OFFSET ROOM A
(1)(3)
-5.0 to +5.0 °C Room offset on circuit A: Is used to set
a room offset
Make this setting 2 hours after switching
on, when the room temperature has
stabilised
0.0
ANTIFR.ROOM A 0.5 to 20 °C Room temperature antifreeze activation
on circuit A
6 °C
CALIBR.ROOM B
(2)(1)
(4)
Calibration of the room sensor on
circuit B
Make this setting 2 hours after switching
on, when the room temperature has
stabilised
Room temperature
of circuit B
OFFSET ROOM B
(3)(4)
(1)
-5.0 to +5.0 °C Room offset on circuit B: Is used to set
a room offset
Make this setting 2 hours after switching
on, when the room temperature has
stabilised
0.0
ANTIFR.ROOM B
(4)
0.5 to 20 °C Room temperature at which the
antifreeze mode is activated on circuit B
6 °C
CALIBR.ROOM C
(4)(1)
(2)
Calibration of the room sensor on
circuit C
Make this setting 2 hours after switching
on, when the room temperature has
stabilised
Room temperature
of circuit C
OFFSET ROOM C
(4)(1)
(3)
-5.0 to +5.0 °C Room offset on circuit C: Is used to set
a room offset
Make this setting 2 hours after switching
on, when the room temperature has
stabilised
0.0
ANTIFR.ROOM C
(4)
0.5 to 20 °C Room temperature antifreeze activation
on circuit C
6 °C
(1) The parameter is only displayed if INSTALLATION is set to EXTENDED
(2) The parameter is only displayed if a room sensor is connected to the circuit concerned
(3) The parameter is only displayed if no room sensor is connected to the circuit concerned or the sensor has no influence
(4) The parameter is only displayed if the circuit concerned is actually connected
Diematic iSystem For C 330 / C 630 ECO 5. Commissioning
31082018 - 7600691-001-06
52
