Using your hob in all simplicity
Ø 23 cm
50 W to 3200 W
Ø 16 cm
50 W to 2200 W
Ø 18 cm
50 W to 2800 W
Ø 21 cm
50 W to 3100 W
To use your hob, it is vital
that you insert the enclosed
batteries in the control unit.
Please see the instructions
for setting up the control
unit when inserting
batteries.
Timer buttons for all
rings
Battery level display
"Lock" display
No radio link display
Hob ON/OFF button
Locking button
Power display for
each ring
Timer display for
each ring
Power buttons for all
rings
Start Control button
Display:
- Time
- Cooking end time
in Start Control
position
Button to select the
front left ring
Button to select the
back left ring
Button to select the
front right ring
Button to select the
back right ring
