Console indoor units (UCE):
Installation requirements:
Ensure that you respect the following installation requirements during installation.
Ceiling installation Installation on the ground
Location of fittings:
Ceiling installation:
1. This mounting system must be strong and sturdy enough to withstand a weight of over 200 kg and to
be able to withstand vibrations over long periods.
2. The indoor unit must be mounted as detailed below:
a. Adjust the positions of the suspension hooks to ensure that the indoor unit is level in all directions.
Use a spirit level to check this, to avoid the risk of water leaks occurring.
b. Tighten the nuts and ensure that the mounting hooks are properly secured to the ceiling.
c. Once the appliance has been installed, ensure that it is securely fixed for safety reasons and that it
does not move from side to side.
3. Only use the lower discharge hole to discharge condensate in ceiling installations
