10
Set the volume of water being used for the test (3.0 ml default).
Use the and buttons to decrease/increase the displayed
value. The patch volume is used to calculate surface density.
Patch Volume
The PosiTector SST can be adjusted to a known conductivity
standard. Use the and buttons to decrease/increase the
displayed value to match the known conductivity of the standard.
In typical use, a calibration adjustment should not be
required. Before performing the adjustment, ensure that the
PosiTector SST test cell has been thoroughly cleaned with DI
water. Ensure that the conductivity standard and PosiTector
SST test cell are at the same temperature.
Cal Adjust
NOTE:
(Calibration Adjustment)
Increases the displayed Gage resolution as follows:
0.1 µS, 0 – 200 µS
1.0 µS, over 200 µS
Gage accuracy is not affected.
Hi Res
NOTE:
When checked (default), the Gage guides the user through a 3-
step test process in accordance with ISO 8502-6. Uncheck
Bresle Mode to use the PosiTector SST as a regular
conductivity meter such as when testing abrasive materials in
accordance with ISO 11127-6 and ASTM D4940-15.
Bresle Mode
Adjusts the volume of built-in speaker (Off, Low, Medium, High).
Sound
Disables the Auto Rotate feature by locking the display in its
current orientation.
Flip Lock
Allows the touch screen functionality to be disabled. All gage
functions can also be controlled using the navigation buttons.
Touch
