Installation
1
Installing the solar panel
□ Place the solar panel mounting bracket (B) on the desired
wall.
□ Mark with a pencil, the four pre-drilled holes in the
mounting bracket on the wall.
□ Utilize a standard power drill to create the mounting holes.
2
Installing the solar panel (continued)
□ Place four plugs (BB) in the mounting holes.
□ Place the solar panel mounting bracket (B) over the four
plugs (BB).
□ Use a Phillips screwdriver to screw in the four screws (AA)
into the pre-drilled holes of the mounting bracket.
Top View
Wall
AAAA
BB
B
BB
