Installation
1
Determining the mounting
location
NOTE: The light xture should be mounted approximately
8 ft. (2.4 m) above the ground.
NOTE: Ensure the xture and the solar panel are located
close enough together for the cord to reach. You can also
add on an extension cord. Ensure the solar panel faces
South.
□ Determine the mounting location - wall or eave
mount.
□ Position the lamp head (A) in the general
direction of the desired light coverage.
Wall Mount Eave Mount
Incorrect
A
2
Setting the sensor for wall or
eave mounting
NOTE: Adjust the sensor angle to a coverage desired.
□ When wall-mounted, the motion sensor (C) can
be tilted downward to an almost 90º angle, and
turned side-to-side to cover a general area.
□ When eave-mounted, the motion sensor (C) can
be tilted outward, or turned side-to-side.
C
C
