Installation
Under-counter installation
Worktop
32mm - 48mm thick
Vent
gap
at
front
only
100
590
Aperture
(210)
Floor
Datum
900
565 Aperture
Top filler piece
Typical section showing
ventilation requirements
Aperture
590 H x 565 W x 570 D
6
+
_
3
0
+
_
3
0
+
_
3
0
Hob installation
( 35 )
560
80
Worktop front
+
_
3
0
485
+
_
3
0
+
_
3
0
• Note: The oven cavity must vent through the front only. Avoid gaps between cupboard
sides and the underside of the worktop.
• Insert the oven into the cupboard.
• Open the door to expose the fixing holes in the side trims.
• Secure the oven by 4 countersunk screws (fasteners are not supplied ).
• The hob should be installed in a ventilated cupboard fitted with a sturdy worktop.
• Secure the hob using the fixing brackets provided.
