Anti-Tilt mechanism
• “A” 1 x Stability chain
• “B” 1 x Stability hook with anchor sleeve
• “A” is factory fitted at the rear of the stove in the centre. (See overleaf for instructions
if the removable splashback is to be fitted)
• Position the stove and move “A” to touch the wall behind the stove.
• Mark the hole where “A” touches the wall behind the stove.
• Move the stove away from the wall to allow for an area to work in.
• Using a 8.0 mm concrete bit, drill a hole at the marked position.
• Using the Stability hook and anchor sleeve “B”, firmly secure “B” to the wall.
• Slide the stove back in position and engage the stability chain “A” onto the Stability
hook “B”.
• The stove is then secured and will not accidentally tilt if downward pressure is applied
to the open oven door.
WARNING: All stoves can tilt if you or a child sit or lean on an open oven
door. Safety regulations stipulate that the ANTI-TILT mechanism supplied with the stove,
must be fitted as shown.
