PAGE 5 OF 12
VERY IMPORTANT SAFETY INSTRUCTION
Safety installation for hobs with control panels only
x A removable horizontal board must be fitted below the hob and 75mm away from the
worktop bottom face.
x Space between this board and the hob must be empty and no objects may be stored or kept
there.
x This board will effectively shield the user from the base of the hob which gets hot during
use. The board needs to be removable for service purposes as the hob, once installed, can
only be loosened from below.
x If the hob is installed with a side adjacent to a vertical kitchen cabinet, the distance between
the edge of the hob and that of the cabinet side must be a least 150mm. The distance
between the back wall and the rear edge of the hob must be at least 55mm.
!
