User manual, Check synchroscope CSQ-3
4189340263L (UK)
Optocoupler output: System status off = failure
NpN optocoupler output
Max. 40V, 10mA
2 wires AWG 20 (red/black)
30 mm length
(Only in marine version)
Temperature: -10…55°C (nominal)
-25…70°C (operating)
-40…70°C (storage)
Temperature drift: Set points:
Max. 0.2% of full scale per 10°C
Galvanic separation: According to EN/IEC61010-1
All input/output groups to ground: 3.75kV
Between all input/output groups: 3.75kV
Test conditions: 50Hz, 1 min.
Climate: HSE, to DIN40040
EMC: CE-marked according to EN50081-1/2, EN50082-1/2
and IEC255-3
Connections: Max. 2.5 mm
2
(single-stranded)
Max. 1.5 mm
2
(multi-stranded)
Materials: All plastic parts are self-extinguishing to UL94 (V0)
Protection: Front: IP52. Terminals: IP20
According to IEC529 and EN60529
Type approval: For current approvals please see www.deif.com
(Only valid for marine version)
UL listing: On request, the instrument can be delivered
according to UL listing:
UL508, E230690
T
ambmax
50°C
For use in a flat surface of type 1 enclosure
Wire: 24-12 AWG
Use 60/75° C copper conductors only
Main disconnect is to be provided by installer
Terminal screw torque: 5-7 lb-in.
Installed in accordance with the NEC (United States)
or the CEC (Canada)
CAUTION: Risk of electrical shock. More than one
main disconnect may be required to de-energize
equipment before servicing.
