Dejavoo Keypad Layouts
All Dejavoo terminals have a number of keys in common. These keys are the same and perform the same function
regardless of the Dejavoo model. Other keys are unique to either one model or a series of models.
Common Keys
KEY FUNCTION
1-0
Number
Keys
• Enter amounts, account numbers, dates and such.
• Alphanumeric entry – multitap to access the alpha characters.
Green OK
• From the idle prompt is used to access the Main Menu
• Functions as the OK key.
Red X
• Cancels a transaction
• Exits menu options to return to idle prompt
Yellow
• Back space to clear data fields
• Back out of menu options one level at a time


Arrow
• Navigate up through the menu options
• Change transaction types


Arrow
• Navigate down through the menu options
• Change transaction types
W
HAT TO EXPECT IN THIS MANUAL – NON TOUCHSCREEN VS TOUCHSCREEN
This manual will provide explanations, important notations, and step/action charts to guide
you through the performance of the V LINE family of terminals and the Z LINE family of
terminals which consist of NON Touchscreen as well as Touchscreen models. However, it’s
important to note that the display examples will reflect that of the Z11 touch screen.
IMPORTANT NOTE: SCREEN DISPLAY EXAMPLES IN THIS MANUAL MAY DIFFER
THAN YOUR MODEL, THE EXAMPLES USED FOR THIS DOCUMENT DEPICT THAT OF
THE Z11 TOUCHSCREEN TERMINAL.
