MAINTENANCE
The shower does not close or the operation time is incorrect:
•
Impurities or damage to the O-ring inside the push-button
starter
1:
SPORTING shower panel
(fig. G):
- Unscrew the screws 4 and remove the end-cap 2.
-
Shut-off the water supply and remove the push-button starter. Unscrew the push-button starter
connection screw
20 for 3 turns
, remove the covering cap of the push-button starter and apply
pressure with a screwdriver to remove the starter.
- Check/clean the O-rings
21 and 22
.
- Replace the push-button starter and covering cap and restore the water supply: press firmly
on the push-button and replace the screw
20 (fig. G, H)
which is inserted in the neck of the
push-button starter. Do not tighten the screw all the way.
- Replace the end-cap 2 and the screws 4
and restore the water supply
.
Wall-mounted exposed or recessed
SPORTING shower (fig. H):
-
Shut-off the water supply and remove the push-button starter using an Allen key.
- Check/clean the O-rings
21 and 22
.
- Replace the push-button starter using an Allen key and restore the water supply.
•
Impurities or damage to the O-ring inside the shower head mechanism:
-
Shut-off the water supply and remove the
mechanism 23 (fig. I) using a pair of circlip pliers (fig. I)
making sure that you remove the washer 24 (fig. J). Remove the piston 27 and the spring 26 (fig. J).
-
Clean the interior of the delay case
25 (fig. J, K)
with a cloth, then the thin calibrated groove
30
(fig. K)
with a non-metallic pointer, and check/clean the lip seal and O-ring washers
28 and
29 (fig. J)
.
- Replace the mechanism, remembering to include the washer
24 (fig. J)
and restore the water
supply.
The shower starts all by itself or the flow is very poor:
Impurities in the filter 8 and/or non-return valve 9 (figs. A, B, C, E): shut-off the water supply and clean them.
• Cleaning chrome:
Do not use abrasive, chlorine or any other acid-based cleaning products. Clean
with soapy water using a cloth or sponge.
• Frost protection:
Drain the pipes and operate the mixer several times to drain any remaining water
.
• If the installation remains unused for a period of time we recommend removing the cartridge
mechanisms from the shower head and push-button starter and store them in the shade at room
temperature.
CLEANING & SERVICING
After Sales Care and Technical Support
:
For Douglas Delabie UK market only: Tel. 01491 824449 email: technical@douglasdelabie.co.uk
For all other markets: Tel.03.22.60.22.74 email: sav@delabie.fr
The most recent version of this installation guide is available on: www.delabie.com
