51launaM s’renwO
SUPERSKID COMPONENT LOCATOR PARTS LIST
Ref. No. Qty. Part No. Description
1 1
ENG0006/GX620
21 HP VANGUARD /20HP HONDA
2 1 PUM0030/TS2021 PUMP TSF2019/ TS2021
3 1 PUL0004 ENGINE PULLEY, 3TB36
N/S 1 D034 ENGINE BUSH, P1X1
4 1 PUL0007 PUMP PULLEY, 2BK90H
5 2 D150 PUMP, V-BELT, B/BP42
6 1 WRA0005 BURNER HOOD (WRAPPER)
7 1 BUR0004 BURNER, 12VDC
8 4 F010 1/4 X 1/4 IN. HOSEBARB
9 4 S063 1/4 IN. HOSE CLAMP
10 3 FT. H012 1/4 IN. NYLON BRAID HOSE
11 1 FIL0006 FUEL FILTER
12 1 F001 1/4 IN. BRASS STREET ELBOW 90°
13 1 TAN0019 BURNER FUEL TANK
14 1 X007 CAP, FUEL CHROME
N/S 1 T114 BURNER HEAD WITH INSULATION
15 1 COW0002 COIL AND TANK ASSEMBLY
N/S 1 T013 COIL W/ INSULATION
16 1 TAN0020 FLOAT TANK, S.S. (COMPLETE ASSEMBLY P/N = TAN0020).
17 1 FLOAT TANK LID, S.S.
18 1 FLOAT VALVE
19 1 FLOAT ROD 1/4 IN. BRASS
20 1 FLOAT BALL
21 1 3/8 IN. SCREEN
22 1 HOSEBARB, 3/8 IN. X 5/8 IN. DRILLED
23 1 1/2 IN. BRASS STREET ELBOW, 90°
24 1 1/2 IN. X 12 IN. GALVANIZED NIPPLE
25 1 GARDEN HOSE CONNECTION S1
26 1 F187 SCREEN AND O-RING
27 1 F034 3/8 IN. MALE QUICK CONNECT
28 1 F048 3/8 IN. X 1/2 IN. BUSHING
29 2 F127 1/2 IN. TEE F.S. 3000#
30 1 S019 HI-TEMP SWITCH
32 1 V048 PRESSURE RELIEF VALVE RV500B
33 1 F129 1/2 IN. X 4 GALV. NIPPLE
34 1 F222 1/2 GALV. 90° ELL SCH. 80
35 1 H007 3/8 IN. X 15 IN. HIGH PRESSURE HOSE
35A 1 H004 3/8 IN. X 26 IN. HIGH PRESSURE HOSE
36 1 S024 PRESSURE SWITCH
37 1 UNL0013 UNLOADER VALVE
N/S 1 TAN0019 TANK, GAS 3005 SKID MS
38 2 F125 3/8 IN. GALV. 90° EL SCH. 120
39 1 F026 3/8 IN. X 3/8 IN. HOSE BARB
40 3 S064 5/8 IN. HOSE CLAMP #6
41 2 FT. H011 3/8 IN. NYLON BRAID HOSE
42 1 F043 3/8 IN. BRASS STREET EL. 90°
43 1 F023 5/8 IN. X 3/8 IN. HOSEBARB
44 3 FT. H008 5/8 IN. NYLON BRAID HOSE
45 2 F019 5/8 IN. X 1/2 IN. HOSEBARB
46 2 F005 1/2 IN. CLOSE NIPPLE, SCH. 80
47 1 F008 1/2 X 1/4 BRASS BUSHING
To Next Page
