Versa 5300 Owner’s Manual 2 3
TS2021 PUMP COMPONENT LOCATOR PARTS LIST
Ref. No. Qty. Part No. (Gen. PN) Description
1 1 47120841 Manifold
1 1 47120941 Manifold - Nickel Plated
2 8 99320600 Screw, M8 x 70
3 8 IP-400-06 (96702000) Flat Washer, M8
4 6 IP-100-09 (99320600) O-Ring
5 6 IP-100-11 (36200366) Valve Seat
6 6 IP-100-13 (36200176) Valve Plate
7 6 IP-100-15 (94737600) Spring
8 6 IP-100-17 (36200251) Valve Guide
9* 6 IP-100-19 (90384700) O-Ring, O-Anillo
10 6 IP-100-21 (98222000) Cap
11* 6 IP-100-23 (36703201) Valve Assembly
12 8 IP-100-49 (99303900) Screw, M18 x 16
13 1 8002255 (47150122) Crankcase Cover
14 2 8001582 (90391300) O-Ring
15 2 IP-500-07 (640047) Roller Bearing
16 3 IP-500-09 (90162500) Oil Seal
17 3 IP-500-11 (90912600) Bushing
18 1 8002256 (47010522) Crankcase
19 1 IP-500-15 (98210600) Oil Dipstick
20 1 IP-500-65 (90392200) O-Rin
21 1 52941A (47021735) Crankshaft
22 6 IP-500-21 (90055700) Retaining Ring
23 1 IP-500-23 (91489000) Key
24 3 IP-500-25 (97738000) Wrist Pin
25 3 IP-500-27 (47050554) Guide, Plunger
26 3 191326 (47030001) Connecting Rod
27 5 IP-500-31 (99191200) Screw, M6 x 30
28 1 IP-800-24 (47160122) Crankcase Cover
29 1 IP-200-24 (97596800) Oil Indicator
30 1 IP-200-26 (98204100) Oil Drain Cap
31 4 IP-200-22 (90358500) O-Ring
32 6 IP-500-35 (99309900) Screw, M8 x 35
33 6 UV-935-06 (96701400) Washer, M8.4
34 3 IP-500-39 (96728600) Washer, M14
35 3 197075 (47040409) Piston,
36 3 IP-500-43 (90506700) Back-Up Ring
37 3 IP-500-45 (96728000) Washer
38 3 IP-200-46 (47219566) Screw, Plunger
39 1 IP-500-47 (47150022) Bearing Housing - Crankcase cover
40 2 IP-500-49 (97567800) Shim
41 1 IP-500-51 (90164800) Oil Seal
42* 3 IP-500-53 (90361600) O-Ring
43 3 IP-500-55 (47080570) Packing Retainer
44* 3 IP-500-57 (90270500) Packing
45* 3 IP-500-59 (47100051) Head Ring
46 3 IP-500-67 (47216970) Intermediate Ring
47* 3 IP-500-71 (90270400) Restop Ring
49 4 IP-100-50 (99364400) Screw, M10 x 18
50 4 IP-100-51 (96710600) Washer, M10.2
51 1 IP-100-45 (98217600) Cap
