launaM s’renwO 81
SUPERSKID COMPONENT LOCATOR
Ref. No. Qty. Part No. Description
1 1 T316 COIL & TANK ASSEMBLY
4 1 T114-SS BURNER HEAD
18 1 B004-SS ADJ. ROD FOR CAT
1 B008-SS ADJ. ROD FOR GENERAL
19 1 B002-SS ADJ. BRACKET CAT
1 B007-SS ADJ. BRACKET GENERAL
36 1 FRA0018 SUB FRAME (ALL VERSIONS) Specify material if other than MS.
1
37 1 FRA0017
FRAME
44 1 TAN0019 TANK GAS
50 1 TAN0019 TANK DIESEL
81 1 WRA0005 BURNER HOOD (WRAPPER)
103 1 T095-SS
SHEILD HEAT/F GENERATOR
N/A
BRA0020 ALTERNATOR BRACKET
100 1 GEN0001 GENERATOR 2000W/120VAC
100A 1 ALT0001 ALTERNATOR
