Delco Pressure Washers - Alternate Burner Components - P;N= BUR0011

Page 30-A
Alternate BURNER COMPONENTS - P/N= BUR0011
MSR BURNER MODEL, PART DESCRIPTION AND PART NUMBER WHEN ORDERING PARTS
*P AR T NUMBER SEE PAGE 7
Suggested Combustion Chamber Dimensions
Conversion or Upgrading
Chamber Dimensions (In Inches)
Firing
Rate
(G.H.P)
Square
Width Length
Round Height Floor
to
Nozzle
NO. DESCRIPTION PART NO.
1 BURNER HOUSING 31841-036
2 JUNCTION BOX ASM 21319
3 MOTOR 1/8 H.P. 20627
4 BLOWER WHEEL 3 1/8 X 4 1/4 20673
BLOWER WHEEL 3 1/2 X 4 1/4 21427
5 MOTOR CORD COVER 13029
6A TRANSFORMER 115V 23101-M
230V 23103-M
6B FRANCE IGNITOR 115V 101050-001
6C CARLIN IGNITOR 230V 31812-002
7A COVER 21723-002
300-32712REVOCB7
7C COVER 100730-001
8 COUPLING 13424
9A FUEL UNIT MODEL A 13495
9B FUEL UNIT MODEL B 13634
9C SUNTEC COMBO UNIT 115V 101128-001
SUNTEC COMBO UNIT 230V 101128-002
10 6” OIL LINE ASSEMBLY 14451
8” OIL LINE ASSEMBL Y 14452
11 INNER AIR BAND 20601-002
12 OUTER AIR BAND 20602-002
NO. DESCRIPTION PART NO.
13 AIR TUBE & GUN ASSM. *
14 GASKET 12484
15 ADJUSTABLE FLANGE 2689-011
16 PEDEST AL MOUNT 21760-011
17 ELBOW 13494
0.85 8.5 8.5 9 12 5-6
1.00 9 9 10
1
⁄8 12
1
⁄2 5-6
1.25 10 10 11
1
⁄4 12
1
⁄2 5-6
1.35 10
1
⁄2 10
1
⁄2 11
3
⁄4 12
3
⁄4 5-6
1.50 11 11 12
3
⁄8 13 5-6
1.65 11
1
⁄2 11
1
⁄2 13 13
1
⁄4 5-6
2.00 12
5
⁄8 12
5
⁄8 14
1
⁄4 13
1
⁄2 6-7
2.50 14
1
⁄4 14
1
⁄4 16 14 7-8
3.00 15
1
⁄2 15
1
⁄2 17
1
⁄2 15 7-8
