Delco VERSA 100C - Parts Lists and Kit Information; Pump Parts List

Versa 100/100C Owner's Manual Page 15
Delco Versa 100 /100C-200C
Pump Parts List
Ref. Part No. Description Qty
1 192323 Cover - Crankcase 2
2 198296 Seal - Oil Bearing 1
3 197070 Plug, Oil 1
4 198092 Screw - M6 x 14 Uni Soc Hd. Cap 5
5 192322 Cover - Crankcase 1
6 198091 Screw M6 x 10 Uni Hex Hd. 8
7 196647 O-Ring 2
8 191615 Bearing - Crankshaft 2
9 193895 Gasket - Crankcase Cover 1
10 193900 Gauge - Oil 1
11 197066 Plug 1
12 196644 O-Ring 4
13 199586 Washer 6.4 x 10 x 0.7 6
14 198209 Screw M6 x 35 Unit Soc Hd Cap 6
15 191328 Rod assembly - Connecting 3
16 199580 Washer 8.4 x 13 x 0.8 6
17 192387 Crankshaft 1
18 Seal - Oil Kit 195423 ref.
19 199581 Washer 14 x 28 x 0.5 3
20 192374 Crankshaft 1
21 195101 Key 1
22 197076 Piston - Plunger 3
23 197627 Washer - 14 x 18.5 x 0.5 3
24 199589 Ring - Backup 3
25 196646 O-Ring 3.47 x 1.78 3
26
Ref. Part No. Description Qty
195401Check Valve Kit 1
Ref. # 38, Valve Assembly (6)
195404Hex Valve Cover, O-Ring Kit 1
Ref # 37, O-Ring (6)
Ref. #36, Hex Valve Cover (6)
195406Plunger Bolt Kit 1
Ref # 27, Plunger Bolt (3)
Ref. #12, O-Ring (3)
Ref #24, Backup ring (3)
Ref #23, Washer (3)
195419 V-Packing Kit 1
195420 Intermediate Ring Kit 1
195421 Male Adapter Kit 1
195422 Female Adapter Kit 1
Ref. #32, Female Adapter (3)
Ref. #25, O-Ring (3)
195423 Oil Deal Crankcase 1
Ref. #18, Oil Seal (3)
195427 Piston Repair Kit 3
Ref. #34, Male Adapter (1)
Ref. #33, V-Packing (1)
Ref. #35, Intermediate Ring (1)
Ref. #32, Female Adapter (1)
Ref. #25, O-Ring (1)
Kit No. Description Qty
27 Bolt - Plunger Kit 195406 ref.
28 197701 Rod - Piston 3
29 196967 Pin - Piston 3
30 198293 Seal Crankshaft 1
31 198294 Seal - Oil Bearing Cover 1
32 Adapter - Female Kit 195422 ref.
33 V-Packing Kit 195419 ref.
34 Adapter - Male Kit 195421 ref
35 Ring Intermediate Kit 195420 ref
36 Cover - Valve Hex Kit 195404 ref.
37 196642 O-Ring 6
38 Valve Assembly Check - Kit 195401 ref.
39 191688 Screw M8 x 60 Uni 8
40 199580 Washer 8.4 x 13 x 0.8 8
41 199583 Washer 21.5 x 27 x 1.5 1
42 197067 Plug - Drain Inlet 1
43 195744 Manifold 1
