Versa 100/100C Owner's Manual Page 25
Ref # P /N Description Qty
64 980603 Washer, Star 3
65 199732 Harness, Wiring O/F 115V 1
66 68403A Under Carriage 18" 1
67 170667 Nut, Wire, Yellow 1
68 911177 Nut, Wire, Orange 4
70 77027A Label, Warning 1
71 191775 Bushing, Strain, Relief 1
72 43102A GFCI 35' 115V 20A 1
73 193943 Grommet
1
/2 x
31
/32 4
74 170636 Connector Conduit
3
/8, I-Screw 1
75 170860 Washer, Flat
5
/16 12
76 193951 Trim (2
@ 3") 6"
77 170966 Hose, 2 Braid
5
/8, (manifold to tank) 13"
170966 Hose, 2 Braid
5
/8, (manifold to unloader) 18"
78 170964 Hose,
1
/4 Fuel (burner to tank-2 @ 52") 104"
170964 Hose,
1
/4 Fuel (manifold to relief valve) 21"
79 44803A Motor 2 hp-115/230V 1
80 57240A Pulley - AK34 x
5
/8"1
81 60139A Axle, Rear 18" 1
82 66359A Panel, Rear 1
83 74106A Label, Sweep, Right 1
84 193871 Gaskets, Burner 2
85 170963 Sleeving, PVC
1
/2 19"
86 170641 Strain, Relief
3
/8 x 90° 2
87 170040 Elbow
1
/4 x 90 3
88 53972A Filter, Asm., Fuel 1
89 53525A Filter, Replacement Element 1
90 170207 Nipple
1
/4 x 2
1
/2 1
91 29620A Burner, Oil 115V w/Solenoid 1
93 196379 Nozzle, Fuel 1.50 x 80° 1
94 60773A Burner Head 1
95 171101 Nut
3
/8-16, Whizlock 3
96 192277 Coupler, Quick ¼" Female 1
97 53508A Extension
1
/4 x 34" 1
98 54223A Trigger, Gun, Asm. 1
99 194350 Hose Asm.
3
/8" R1 x 50' 1
100 194387 Hose,
3
/8" x 26" 1
101 170242 Elbow, Street
3
/8 Galv. 2
102 170027 Hosebarb
5
/8 x
1
/2 1
103 170228 Coupling,
3
/4 x
1
/2 1
104 59403A Valve, Unloader K3.1 1
105 170419 Nipple, Pipe
1
/2 x 5
1
/2 1
106 170248 Elbow
1
/2 Galv., Side Outlet 1
107 59733A Relief, Valve 2K 1
108 170637 Connector, Conduit
3
/8 2-Screw 1
109 170956 Coupling, Pipe,
1
/2"PVC 1
110 170418 Nipple, Pipe
1
/2 x 5 Blk. 1
111 198491 Switch, Hi-Temp 230° 1
112 170258 Tee, Reducing ½" x
3
/8" x ½" 1
113 170215 Nipple
3
/8 x 6 1
114 170237 Elbow,
3
/8" Galv. 1
115 192276 Coupler, Quick
3
/8 MPT 1
116 77033A Label, Warning 1
117 197056 Nipple, Coupler, Quick
3
/8 Male 1
118 170858 Washer, Flat
1
/4"SS 4
119 171112 Screw
1
/4-20 x
1
/2 Truss 6
120 191785 Button, Darts 4
121 170793 Nut, Clinch ¼-20 6
122 77032A Label, Danger Steam 1
123 67526A Shield, Heat 18" S.S. 1
124 198078 Screen, Hose, Washer 1
125 170071 Fitting
3
/4 x
1
/2 Female 1
126 170216 Nipple, Pipe
1
/2 x Close Galv. 1
127 170222 Nipple, ½" x 6" 1
128 170402 Nipple, ¼ Close Blk. 1
(Part list continued on next page.)
Ref. # P/N Description Qty
1 29645A Pyrolite drum head insulator 1
2 29644A Pyrolite Disc 1
3 61645A Coil, 18" w/2 pancakes 1
4 194803 Insulation 1
5
6 170219 Nipple
1
/2" x 2
1
/2"1
7 198072 Screen, Tank
1
/2"1
9 199067 Valve, Float* 1
10 191519 Ball, Float* 1
11 45400A Wire Nut - Red 1
12 699202 Wire Tie 7
13 170906 Screw #10 X
1
/2 7
14 930093 Pop, Rivet
1
/8 x
1
/4-
5
/16 3
15 16800A Lid, Weldmt., Float 1
16 77030A Decal, Instruction Lid 1
17 52052A Cap, Fuel Gauge 1
18 77028A Label, Fuel Caution 1
19 68353A Tank Asm. 18" S.S. 1
20 85811A Screw
5
/16-18 x
3
/4 2
21 980652 Washer,
5
/16" Lock 13
22 194208 Grip, Handle
7
/8 I.D. 1
23 64435A Handle, Tow 1
24 29576A Strainer w/check valve 1
25 194219 Rack, Hose 2
26 85813A Screw
5
/16-18 x 1 10
27 68502A Support V-Front 1
28 50429A Palnut
5
/8"4
29 60140A Axle, Front 1
30 59958A Wheel 4
31 170875 Washer, 2¼" O.D. x 1¼" I.D. 1
32 170818 Screw
5
/16-18 x 1
3
/4 1
33 170940 Pin, #10 Hitch 1
34 170854 Nut,
5
/16-18 Hx 9
35 192501 Plate, Serial 1
36 170927 Rivet, Pop
1
/8" S.S. 4
37 193944 Grommet, Rubber
3
/4" x 1
3
/8"2
38 68368A T-Bar Weldment 1
39 195693 Manifold, Intake 1
40 720271 Adapter ¼" 9
41 722021 Clamp - ¼" Hose 9
42 170066 Tee
1
/4 Brass NPT 1
43 170086 Nipple
1
/4 Close 1
44 170034 Hosebarb
5
/8 x
3
/8 2
45 192116 Clamp - Hose #10 4
46 199081 Metering Valve 1
47 193947 Grommet, Rubber
7
/16" x
15
/16"4
48 197051 Nipple, Coupler, Quick ¼" 4
49 196180 Nozzle, 5.0 x 40°
1
/4"SS 1
50 56255A Nozzle, 5.0 x 15° x
1
/4"SS 1
51 196179 Nozzle, 5.0 x 0° x
1
/4"SS 1
52 196155 Nozzle, 5.0 x 25° x
1/
4
"SS 1
53 52041A Plug - ½" 1
54 77031A Decal, Instruction Control Panel 1
55 72123A Label, Versa 100C I.D. 1
56 74105A Label, Sweep Left 1
57 198450 Switch, Cam 5 hp 1
58 170910 Screw, Tapping
5
/16" x
3
/4"6
59 66358A Panel - Weldment, Control 1
60 170974 Tubing, PVC
1
/4"
(strainer to metering valve) 8'
(metering valve to manifold) 19"
(bottom of tank to drain) 15"
61 85814A Screw
5
/16-18 x 1¼" 6
62 170886 Washer, Flat
1
/4 4
*Note: 191337 Valve Asm. Float
includes 9, 10, 148
Delco Versa 100C-200C Stainless Steel
Machine Assembly Parts List
To Next Page
