Page 22 Versa 100/100C Owner's Manual
119 171112 Screw
1
/4-20 x
1
/2 6x
121 170793 Nut, Clinch ¼-20 6 x x
122 77032A Label, Danger Steam 1 x x
123 198326 Shield, Heat 18" Painted 1 x x
124 198078 Screen, Hose, Washer 1 x x
125 170071 Fitting
3
/4 x
1
/2 Female 1 x x
126 170216 Nipple, Pipe
1
/2 x Close Galv. 1 x x
127 170222 Nipple
1
/2" x 6" 1 x x
128 170402 Nipple,
1
/4 Close Blk. 1 x x
129 170486 Plug, Pipe
1
/4 Blk. 1 x x
130 170252 Tee, Pipe
1
/4 Galv. 1 x x
131 195101 Key - 8 x 7 x 25 1 x x
132 194402 Hosebarb
5
/8 x
3
/8 w/
7
/32" OR 1 x x
133 170265 Tee
1
/2 x
1
/2 x
3
/8 1xx
134 56329A Nipple
1
/4 x 2
1
/2 Sch. 40 1 x x
135 170221 Nipple, Pipe
1
/2 x 4 Galv. 1 x x
136 198433 Switch, Vacuum 1 x x
137 80501A Key
3
/16" x
3
/16" x 1¼" 1 x x
138 170014 Plug, Pipe
1
/2' Brass 1 x x
139 231131 Bushing, Reducing 1 x
140 170850 Nut, Panel
5
/16-18 6 x x
141 170004 Bushing, Pipe
3/
8
x
1/
8
Brass 1 x x
142 199027 Valve, Air
1
/8" NPT Brass 1 x x
143 57239A Pulley AK59H 1 x x
144 197283 Pump, Water W99 1 x x
145 191773 Bushing, Pulley H x 24mm 1 x x
146 191679 Belt-V A30 1 x x
147 194117 Hook, Gun 2 x x
148 29575A Nut, Retaining* 1 x x
149 77024A Label, Warning, Electric 1 x x
150 77039B Label, Made in USA 1 x x
Delco Versa 100/100C Painted
Machine Assembly Parts List
Versa 100C
Versa 100
Ref. # P/N Description Qty
