Delixi CDB6i - Normal use, installation and transport conditions; Normal use and installation conditions; Normal storage and transport conditions; Technical characteristics

2
please stop using it.
3 Normal use, installation and transport conditions
3.1 Normal use and installation conditions
a) The upper limit of ambient air temperature does not exceed +70℃, the lower limit does not exceed -35℃,
and the average temperature within 24 hours does not exceed +35℃;
b) The altitude of the installation site does not exceed 2000m;
c) When the temperature is +40°C, the relative humidity of the air does not exceed 50%; at a lower
temperature, a greater relative humidity is allowed. For example, at +20°C, the relative humidity does not
exceed 90%. Special protective measures shall be taken for the condensation produced occasionally due to
temperature changes;
d) The external magnetic field near the circuit breaker installation site should not exceed 5 times the
geomagnetic field in any direction;
e) Installed in a medium without explosion hazard, and there is no enough gas and dust that cause corrosion
to metals and destroy to insulation in the medium;
f) Installed in the place without significant impact vibration and rain and snow invasion;
g) Pollution level: Level 2;
h) Installation category: CategoryⅡ , Category Ⅲ ;
i) Installed in the power distribution box, electric distribution cabinet or box;
j) Reverse wiring is allowed for product;
k) When wiring products with N pole, connect the neutral wire (zero line) to the pole marked with N.
3.2 Normal storage and transport conditions
a) The lower temperature limit is not less than -40℃, and the upper limit is not more than +85℃;
b) Relative humidity (at 25℃ ) does not exceed 95%;
c) Handle the product gently during transport, do not upside it down and try to avoid violet collisions.
4 Technical characteristics
4.1 Main technical performance parameters
a) The main technical parameters of the circuit breaker see Table 1
Table 1 Main technical parameters
Trip type
Rated current In A
Number of poles
Rated voltage Ue V
Rated breaking capacity Icn A
B、C、D
1、2、3、4、5、6、8、
10、13、16、20、25、
32、40、50、63
1P
AC230/400V
AC240/415V
6kA
1P+N
AC230/240V
2P
AC400/415V
3P
3P+N
4P
b) Overcurrent protection characteristics of circuit breakers are shown in Table 2
Table 2 Overcurrent protection characteristics of circuit breaker
Release type
Rated current
In A
Test current
A
Starting state
Starting
time
Expected
results
Remarks
Reference
temperature
B, C, D
≤63
1.13In
Cold state
t≤1h
No trip



℃
B, C, D
≤63
1.45In
Immediate test
t＜1h
Trip
Current rises to
the specified
value within 5s
B, C, D
≤32
2.55In
Cold state
1s<t<60s
Trip
B, C, D
＞32
1s<t<120s
B
≤63
3In
Cold state
t≤0.1s
No trip
Turn on the
auxiliary switch to
power on
C
5In
D
10In
B
≤63
5In
Cold state
t＜0.1s
Trip
Turn on the
auxiliary switch to
C
10In
