Figure 21. 5U84 controller enclosure—rear panel components (4-port FC/iSCSI)
1 Controller module slot A 2 Controller module slot B
3 FCM slot 0 4 FCM slot 1
5 FCM slot 2 6 FCM slot 3
7 FCM slot 4 8 PSU slot 0
9 PSU slot 1
Figure 22. 5U84 controller enclosure—rear panel components (4-port SAS)
1
Controller module slot A 2 Controller module slot B
3 FCM slot 0 4 FCM slot 1
5 FCM slot 2 6 FCM slot 3
7 FCM slot 4 8 PSU slot 0
9 PSU slot 1
18 Storage system hardware
