Technical specifications
Topics:
• Physical specifications
• Dimensions and weight
• Power requirements
• Operating limits
• Shipping and storage requirements
Physical specifications
Table 14. Physical specifications
Per Appliance 1000 3000 5000 7000 9000
CPU 4 x Intel CPUs, 32
cores, 1.8 GHz
4 x Intel CPUs, 48
cores, 2.1 GHz
4 x Intel CPUs, 64
cores, 2.1 GHz
4 x Intel CPUs, 80
cores, 2.4 GHz
4 x Intel CPUs, 112
cores, 2.1 GHz
Memory 384 GB 768 GB 1,152 GB 1,536 GB 2,560 GB
Embedded SAS I/O
ports
4 x 4 lane 12 Gb/s SAS ports for back-end connection
Dimensions and weight
Base enclosure
Table 15. 2U, 25-drive base enclosure dimensions and weight
Dimension Value
Weight (fully populated) 41.7 kg (92 lbs)
Vertical size 2 NEMA units
Height 8.64 cm (3.4 in)
Width 44.45 cm (17.5 in)
Depth 79.5 cm (31.3 in)
NOTE: The weight does not include mounting rails. Allow 3.6 kg (8 lbs) for a rail set.
2U, 25-drive expansion enclosure
Table 16. 2U, 25-drive expansion enclosure dimensions and weight
Dimension Value
Weight (fully populated) 34.98 kg (77.11 lb)
Vertical size 2 NEMA units
Height 8.64 cm (3.4 in)
Width 44.45 cm (17.5 in)
4
18 Technical specifications
