Dell EMC PowerSwitch N3248P-ON User Manual

wall- or ceiling-mount tray
2. Screw the DIN buckles to the bottom of the wall- or ceiling-mount tray using three screws for each DIN buckle.
3. Slide the switch into the wall-mount tray.
4. Line up the two mushroom-head hooks on the switch to the tray hook cutouts until the switch locks into place.
5. Fix the switch to the tray using two screws on each side.
6. Snap the two DIN buckles into the DIN rails.
30
N3200-ON Series switch installation
