Dual-EPAs two-post front-mount installation
To install two EPA power adapter holders in a front-mount two-post rack:
NOTE: This installation instruction procedure applies to the N3208PX-ON switch only.
NOTE: For this installation, you need two-rack units of space in your mounting rack. Install the switch in the bottom portion
of the two-rack units and keep the top portion open.
1. Align the mushroom heads on one power adapter holder with the two cutouts on the second power adapter holder and slide
together.
2. Secure the two power adapter holders together with four screws—two at the front and two at the back of the assembly.
3. Install the two EPAs in your power adapter assembly and secure with metal straps and screws.
For EPA installation instructions, see Power adapter holder assembly.
4. Align the right L-bracket with the mushroom heads on the right side of the assembly.
Face the L-bracket flange towards the front of the assembly.
5. Secure the left L-bracket with four screws.
50
External power adapter

Dell EMC PowerSwitch N3248P-ON Specifications

General

Form Factor	Rack-mountable
Product Type	Switch
Manageable	Yes
Ports	48
Total Number of Network Ports	48
Number of SFP+ Ports	4
Number of Network (RJ-45) Ports	48
Number of Total Expansion Slots	4
Expansion Slot Type	SFP+
Switching Capacity	176 Gbps
Power over Ethernet (PoE)	Yes
Max PoE Budget	740W
Redundant Power Supply Supported	Yes
Media Type Supported	Twisted Pair
Ethernet Technology	Gigabit Ethernet, 10 Gigabit Ethernet
Network Technology	10/100/1000Base-T
Forwarding Rate	130.95 Mpps
Operating Temperature	32 °F to 113 °F (0 °C to 45 °C)
Operating Humidity	10 to 90% non-condensing
Power Source	AC
