N3200-ON Series switch
The following sections describe the Dell EMC N3200-ON Series (N3208PX-ON, N3224T-ON, N322F-ON, N3224P-ON,
N3224PX-ON, N3248TE-ON, N3248P-ON, N3248X-ON, and N3248PXE-ON) switches:
Topics:
• Introduction
• Features
• Physical dimensions
• LED display
• Prerequisites
• N3200-ON Series switch configurations
• Luggage tag
Introduction
The N3200-ON Series switches are compact and full width, one rack unit (RU), full-featured fixed form-factor switches.
Table 1. N3200-ON Series switch summary
Marketing model name (MMN) Description Power supply unit (PSU) and fans
N3208PX-ON
● 4 ports 1G BASE-T RJ45 with
802.3bt Type-4 (90W) PoE
● 4 ports 5G BASE-T RJ45 multigigabit
ports with 802.3bt Type-4 (90W)
PoE
● 2 ports 10G SFP+
● 1 fixed AC PSU
● (optional) Up to 2 external power
adapters
● 1 fixed fan
N3224T-ON
● 24 ports 1G BASE-T RJ45
● 4 ports 10G SFP+
● 2 ports 100G QSFP28 stacking
● 2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
● 3 pluggable fan modules
● Normal and reverse airflow options
N3224F-ON
● 24 ports 1G SFP
● 4 ports 10G SFP+
● 2 ports 100G QSFP28 stacking
● 2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
● 3 pluggable fan modules
● Normal airflow only
N3224P-ON
● 24 ports 1G BASE-T RJ45 ports with
802.3at (30W) PoE
● 4 ports 10G SFP+
● 2 ports 100G QSFP28 stacking
● 2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
● 3 pluggable fan modules
● Normal airflow only
N3224PX-ON
● 24 ports 10M/100M/1G/
2.5G/5G/10G BASE-T RJ45
multigigabit ports with 802.3bt
Type-4 (90W) PoE
● 4 ports 25G SFP28
● 2 ports 100G QSFP28 stacking
● 2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
● 1 EPS (optional and conected from
MPS-1S or MPS-3S power shelf)
● 3 pluggable fan modules
● Normal airflow only
N3248TE-ON
● 48 ports 1G BASE-T RJ45
● 4 ports 10G SFP28
● 2 pluggable AC PSUs—1 default and
1 optional or 2 optional DC PSUs
2
8 N3200-ON Series switch
