Dell 2000FP LCD Monitor Service Guide
Alignment Procedure
Confidential
3
PIP function
No. Monitor settings Signal source Criteria
1 S-Video with DVD-NTSC
2
Main source: D-SUB or DVI displaying normally
PIP source: S-Video and PIP size: Large
S-Video with DVD-PAL
3 Comp. with DVD-NTSC
4
Main source: D-SUB or DVI displaying normally
PIP source: Comp. and PIP size: Large
Comp. with DVD-PAL
DVD video is displaying normally.
Any noise will not be acceptable
Video function
No. Monitor settings Signal source Criteria
1 S-Video with DVD-NTSC
2
Main source: S-Video
S-Video with DVD-PAL
3 Comp. with DVD-NTSC
4
Main source: Comp. video
Comp. with DVD-PAL
DVD video is displaying normally.
Any noise will not be acceptable
Default settings
No. Item Default values
1 Brightness 90
2 Contrast 50
3 Color temperature 6500K
4 Image scaling Fill
5 Language English
6 OSD hold time 20
Color temperatures
Color temperature The x coordinate The y coordinate
9300K 283±30 297±30
6500K 313±30 329±30
Brightness uniformity
Input source: D-SUB or DVI-D running at UXGA 60Hz
No. Item Spec
1 Brightness (center point) 250 cd/m
2
2 Uniformity (9 points) Lmin/Lmax > 70%
Power consumption
No. Item Spec
1 Power saving < 5W
2 Normal operation  60W
Serial Number recording & DDC checking (Both D-SUB and DVI)
On-Line QA / Cosmetic Inspection
Packing
