6-80 Dell PowerEdge 2100/180 and 2100/200 Systems User’s Guide

Figure 6-3. Inside the Chassis—Front/Right Side View

system power supply

diskette drive interface cable

system board

mounting plate

diskette drive

power cables

cooling fan

control panel cable

SCSI cable

CD-ROM drive

internal hard-disk drive cage

bay for third drive

control panel
