Dell 2208WFP User Manual

Attaching the Soundbar
Removing the Stand
Complete the following steps to remove the stand:
1. Rotate the stand to allow access to the stand release button.
2. Press and hold the Stand release button.
3. Lift the stand up and away from the monitor .
Back to Contents Page

NOTICE: Do not use with any device other than Dell Soundbar.
NOTE:Soundbar Power Connector -12V DC output is for optional Soundbar only.
1.
Working from the rear of the monitor, attach Soundbar by aligning the two slots with the two tabs along the bottom rear of the monitor.
2.
Slide the Soundbar to the left until it snaps into place.
3.
Connect the Soundbar with the DC power connector.
4.
Insert the mini stereo plug from the rear of the Dell Soundbar into the computer's audio output jack.
NOTE: To prevent scratches on the LCD screen while removing the stand,ensure that the monitor is placed on a clean surface.

Dell 2208WFP Specifications

General

Pixel pitch	0.282 x 0.282 mm
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Viewable size, vertical	296.1 mm
Viewable size, horizontal	473.76 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
HDCP	Yes
USB hub version	2.0
USB Type-A downstream ports quantity	4
Product color	Black
Market positioning	Business
Power requirements	AC 120/230 V ( 50/60 Hz )
Panel mounting interface	100 x 100 mm
Input current	2 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	75 W
Power consumption (off)	1 W
Power consumption (standby)	2 W
Power consumption (typical)	45 W
Package weight	12650 g

Weight and Dimensions

Depth (with stand)	255.75 mm
Width (with stand)	511.41 mm
Height (with stand)	437.04 mm
Weight (with stand)	9820 g
