Dell 2208WFP - Electrical Specifications; Physical Characteristics; Environmental Characteristics

VESA, 1152 x 864
67.5
75.0
108.0
+/+
VESA, 1280 x 1024
64.0
60.0
135.0
+/+
VESA, 1280 x 1024
80.0
75.0
135.0
+/+
VESA, 1680 x 1050
65.2
60.0
146.3
-/+
VESA, 1680 x 1050
64.6
60.0
119.0
+/-
Electrical Specifications
Video input signals
Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance
Digital DVI-D TMDS, 600mV for each differential line, positive polarity at 50
ohm input impedance
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free TTL level,
SOG (Composite SYNC on green)
AC input voltage/frequency/current
100 to 240 VAC / 50 or 60 Hz + 3 Hz / 2.0A (Max.)
Inrush current
120V:42A (Max.)
240V:80A (Max.)
Physical Characteristics
Connector type
15-pin D-subminiature, blue connector; DVI-D, white connector
Signal cable type
Digital: Detachable, DVI-D, Solid pins, shipped detached from the monitor
Analog: Detachable, D-Sub, 15pins, shipped attached to the monitor
Dimensions (with stand)
Height (Compressed)
14.18 inches (360.24 mm)
Height (Extended)
18.12 inches (460.24 mm)
Width
20.13 inches (511.41 mm)
Depth
5.45 inches (138.50 mm)
Dimensions (without stand)

Height
13.19 inches (334.94 mm)
Width
20.13 inches (511.41 mm)
Depth
2.56 inches (65.00 mm)
Stand dimensions

Height (Compressed)
12.58 inches (319.53 mm)
Height (Extended)
14.24 inches (361.18 mm)
Width
15.96 inches (405.30 mm)
Depth
7.73 inches (196.50 mm)
Weight

Weight with packaging
18.78 lbs (8.53 kg)
Weight with stand assembly and cables
14.87 lbs (6.75 kg)
Weight without stand assembly
(For wall mount or VESA mount considerations -
no cables)
10.88 lbs (4.94 kg)
Weight of stand assembly
3.99 lbs (1.81 kg)
Environmental Characteristics
Temperature

Operating
5°to35°C(41°to95°F)
Non-operating
Storage: -20°to60°C(-4°to140°F)
Shipping: -20°to60°C(-4°to140°F)
Humidity

Operating
10% to 80% (non-condensing)
