Dell 2208WFP - Identifying Parts and Controls

Back View
Side View
Front panel controls
Label
Description
1
Input Source select
2
OSDMenu/Selectbutton
3
Brightness & Contrast/Down (-) button
4
Auto-adjust/Up (+) button
5
Power button (with power light indicator)
Back view
Back View with monitor stand
Label

Description
1
VESA mounting holes (100mm)
(Behind attached base plate)
Use to mount the monitor.

2
Barcode serial number label
Refer to this lable if you need to contact Dell for
technical support.
3
Security lock slot
Use a security lock with the slot to help secure your
monitor.
4
Dell Soundbar mounting brackets
Attach the optional Dell Soundbar.
5
Regulatory rating label
Lists the regulatory approvals.
6
Stand removeal button
Press to release the stand.
7
Cable management hole
Help organize cables by placing them through the hole.
8
Lock down/release button
Push the monitor down, press the button to unlock the
monitor, and then lift the monitor to the desired height.
